Thermal Security Camera

Reach-7

iTherml Thermal Security Camera Reach-series produce high-quality video without any light conditions and are able to detect activity in total darkness, through smoke, fog, rain and haze, providing situation awareness in perimeter, port and airport applications or where artificial light is either unavailable or restricted.

Reach series IP Thermal Security Camera is also capable of providing an analog video output with 720 x 576 thermal video resolution, provide outstanding sensitivity below 40mK at f/1.0, It is capable of multiple display formats, including white hot, black hot, and various color signatures.

Technical Features

■  Advanced WDR image processing
■  640 x 512 pixels
■  Thermal sensitivity (NETD) <40mK @ f/1.0
■  Onvif for interoperability
■  Multiple lens available
■  IP66 encapsulation
■  PoE power supply and video output (optional)
■  Temperature detection (optional)

Technical Parameters

Thermal Camera

Detector Data

Detector Type

Uncooled LWIR detector

IR Resolution

640 x 512 pixels

Pixel Pitch

12μm

Spectral Range

8~14μm

Frequency

50Hz | 60Hz

IR Lens Data

Focal Length

9 mm, 13 mm, 19 mm, 25 mm, 35 mm

Thermal Camera

FFC Duration

<0.5s

NETD

<40mK @ f/1.0

Camera Settings

Image mode (AGC), digital zoom, false color or monochrome thermal video
contrast, brightness, sharpness, system settings

Temperature Detection (Optional)

Temperature Range

-20℃ ~ +150℃, (-20℃ ~ +500℃ optional)

Accuracy

±2℃ & ±2%

Measurement Analysis

Spots, Areas, Isotherm temperature measurement, Temperature alarm

Day Camera

Day Camera

Resolution

2MP

Focal Length

4 mm, 6 mm, 12 mm, 14.8 mm

Smart Function

Smart Functions

Video Fusion (optional)

Picture-in-picture supported (in day camera video)

Video Analysis (optional)

1. Intelligent analysis: support intrusion detection, boundary-crossing detection
entering/leaving area detection, movement detection;
2. Support automatic detection of objects such as people, vehicles and ships;
3. Support fire detection function, linkage alarm output, linkage snapshot.

General

System Features

Video Compression

H.264/H.265

I/O Alarms

1/1

Network

1 RJ45 10M/100M adaptive Ethernet port

Network Protocols

IPv4/6, RTSP/RTP/RTCP, TCP/UDP, HTTP, HTTPS
DHCP, DNS, FTP, DDNS, ICMP, IGMP, NTP

Platform

Onvif 2.5

Web Browser

Supported (IE8 or higher/Chrome/Edge)

Heater | Fan

Supported (optional)

IP Encapsulation

IP66

Weight (approx.)

1.5 kg (≥50 mm lens)
0.6 kg (≤25 mm lens)

Size

∅91 mm x 314 mm (≤50 mm lens)
∅66 mm x 242 mm (≥25 mm lens)

Power Supply

VDC 12V
PoE/802.3af (optional)

Operating Temperature Range

-20℃ ~ +60℃
-40℃ ~ +60℃ (optional)
